SEM500 series roller technical parameters ·
|
||||
| unit | SEM518 | SEM520 | SEM522 | |
| rated power | （kw） | 129 | 129 | 140 |
| work quality
|
（kg） | 18,000 | 20,000 | 22,000 |
| ·
Static linear pressure ·
|
（N/cm） | 415 | 461 | 507 |
| ·
Front and rear axle loads ·
|
（kg） | 9,000/9,000 | 10,000/10,000 | 11,000/11,000 |
| ·
High/low excitation force ·
|
（KN） | 327/188 | 360/208 | 374/215 |
| ·
High/low vibration frequency ·
|
（Hz） | 30/28 | 30/28 | 30/28 |
| ·
Large/small amplitude ·
|
（mm） | 2.0/1.0 | 2.0/1.0 | 2.0/1.0 |
| ground speed
|
（km/h） | 2.98/5.88/9.6 | 2.98/5.88/9.6 | 2.98/5.88/9.6 |
| work pacing | （km/h） | 0-2.98 | 0-2.98 | 0-2.98 |
| gradeability | （%） | 34 | 34 | 34 |
| ·
Compaction width ·
|
（mm） | 2,130 | 2,130 | 2,130 |
| minimum turning radius | （mm） | 6,350 | 6,350 | 6,350 |
|
SEM500 series roller optional |
|||
| Configuration (o= optional) | SEM518 | SEM520 | SEM522 |
|
20.5-25 Diamond tyre |
o | o | o |
| 20.5-25agricultural tyre | o | o | o |
| heating and cooling air conditioner | o | o | o |
|
High temperature fan |
o | o | o |
| hydraulic turnover mechanism | o | o | o |
|
Luxury hover seat with swivel function |
o | o | o |
| warm braw | o | o | o |
| Radio/rotary warning light/rear wiper | o | o | o |
|
Bump wheel/scraper |
o | o | o |
|
Large bump wheel/scraper |
o | o | o |
