SQ5SK2Q/SQ5SK3Q

The boom can be removed to match different truck models

Structural design:

Both boom models feature advanced structural design, including a pentagonal, hexagonal and octagonal arm cross-section design, as well as the U-shaped circular arm design used in the latest generation of products. These designs not only reduce the weight of the lifting arm, but also improve the amplitude and stability of the arm, thus enhancing the lifting capacity.

Power source:

The power of the SQ5SK2Q and SQ5SK3Q boom comes entirely from the pressure energy of the hydraulic oil. Through the high-pressure hydraulic oil to promote the reciprocating movement of the cylinder piston, or drive the hydraulic motor rotation, so that the hydraulic winch and the rotary mechanism rotation, so as to achieve the lifting, rotating and lifting of goods.

Advanced technology:

These two bumpers also use a variety of advanced technologies, such as single-cylinder cable synchronous expansion technology, advanced research and development means, compact hinge design, standard anti-roll alarm device. The application of these technologies not only improves the working efficiency, but also enhances the safety and stability of the boom.

Ease of operation:

The SQ5SK2Q and SQ5SK3Q bumpers are easy to operate. Boarding and getting off together with a control valve, standing on the crane, the control process is simple and convenient, with a better view, you can directly see the inside of the cargo box when working.

In short, SQ5SK2Q and SQ5SK3Q boom have become important products in the field of truck cranes with their unique design, advanced technology and wide application fields.
